Lighting automation

Home Case Studies Lighting automation Back
Case Studies



Advantages

What do I need

How to do it

+ comfort
+ no need for manual switching lights on / off
+ no problem when one forgets to turn the lights off, the lights will turn off itself after the set period
+ it is possible to turn on the whole group of lights (although each one has its own switch)
+ motion sensor
+ digital light switch
+ controller
+ light
+ power supply
+ SD card
+ software

+ connect strategically positioned motion sensor or digital lightswitch to the digital input of the controller
+ connect the light to digital (relay or transistor) output
+ set the rules for lights in software

Example: if the signal from the motion sensor is received, turn the lights on for 30 sec
Example: if a pulse is received from the digital light switch, turn on the lights 1, 2 and 3, if they are off, turn off if they are on
